Name: kaemeasu 4 ~ 20mA Stainless Steel Temperature Sensor Industrial High Temp Infrared Pyrometer Transmitter
Brand: Shenzhen Kace Technology Co., Ltd.
SKU: KM-TP
Price: 89.50 USD
Availability: InStock

Home > products > Temperatures Meter >

kaemeasu 4 ~ 20mA Stainless Steel Temperature Sensor Industrial High Temp Infrared Pyrometer Transmitter

Industrial High Temp Temperature Transmitter

4 ~ 20mA Temperature Transmitter

Stainless Steel Temperature Transmitter

Place of Origin:

China

Brand Name:

kaemeasu

Certification:

Model Number:

KM-TP

Request A Quote

kaemeasu 4 ~ 20mA Stainless Steel Temperature Sensor Industrial High Temp Infrared Pyrometer Transmitter

Product Details

Temp Range:

0~(100-1200)℃

Payment & Shipping Terms

Minimum Order Quantity

Price

USD$59.5~USD$121 per pcs

Packaging Details

paper box-19*11*4.5cm

Delivery Time

5-8 days work days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

1000 pcs per month

kaemeasu Temperature Laser Aiming Transmitter Non Contact Pyrometer Temperature Sensor -50~1200℃

Get Best Price

kaemeasu Temperature Transmitter 4~20mA Output Laser Pyrometer Temp Sensor -50~600℃

Get Best Price

kaemeasu 4-20mA Industrial Pyrometer Non Contact Infrared Temperature Sensor -50~300℃

Get Best Price

kaemeasu 4~20 mA Stainless Steel Transmitter Non Contact Infrared Temperature Sensor -20~600℃

Get Best Price

+86 13316431028

jerry@kaemeasu.com

Contact Now

Product Description

Infrared Temperature Transmitter

kaemeasu 4 ~ 20mA Stainless Steel Temperature Sensor Industrial High Temp Infrared Pyrometer Transmitter 0

Millisecond response time | Multiple output signal options

技术指标Specifications:
测温精度Accuracy	≥100℃ ±1%/≤100℃ ±1℃
测量距离比率(物距比) Distance to spot ratio	(20:1)
光谱范围 Spectral response	8-14μm
响应时间Response time	200ms
发射率Emissivity(EMS)	0.95
重复精度Repeatability	±0.5% or ±0.5℃
供电电压 Power	DC 12~36V
模拟输出 Analog output	4~20mA/0-5V/0-10V/RS485
最大电流 The maximum current	50mA
防护等级Protection level	IP56
环境温度Environmental temperature	0~60℃
存储温度Storage temperature	(-20~80℃)
相对湿度Repeatability	10-95%
隔离Isolation	电源,数字输出,模拟输出,都是相互隔离的,互不干扰 Power, digital output and analog output are isolated and do not interfere with each other.
外壳Shell material	不锈钢Stainless steel
电缆长度 Standard wire length	2m标配 (可定制5m,10m及特殊规格) 2m (or can be 5m or 10m or other length you need.)
CE认证	符合欧盟抗电磁干扰标准 With CE approval and protection against electromagnetic disturbance for EU standard.

kaemeasu 4 ~ 20mA Stainless Steel Temperature Sensor Industrial High Temp Infrared Pyrometer Transmitter 1

01:Sensor probes
02:Internal structure(By optical system, optical detector and other electronic
circuits integrated)
03:Quality Cable Wires
04:Double nut fixing installation
05:304 stainless steel housing

kaemeasu 4 ~ 20mA Stainless Steel Temperature Sensor Industrial High Temp Infrared Pyrometer Transmitter 4

Advanced optical lens is used inside.
It can better receive the infrared radiation of the measured object.
Measurement is more accurate.

kaemeasu 4 ~ 20mA Stainless Steel Temperature Sensor Industrial High Temp Infrared Pyrometer Transmitter 6
